Launch |
| Announced |
2019, February 25 |
|
|
|
| Status |
Available. Released 2019, March 18 |
|
|
|
Network |
| Technology |
GSM / HSPA / LTE |
|
|
|
| Speed |
HSPA, LTE |
|
|
|
| 2G bands |
GSM 850 / 900 / 1800 / 1900 |
|
|
|
|
HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100 - SM-A505U |
|
|
|
| 3G bands |
HSDPA 850 / 900 / 1900 / 2100 |
|
|
|
| 4G bands |
1, 3, 5, 7, 8, 20, 38, 40, 41 |
|
|
|
Body |
| Dimensions |
158.5 x 74.7 x 7.7 mm (6.24 x 2.94 x 0.30 in) |
|
|
|
| Weight |
166 g (5.86 oz) |
|
|
|
| SIM |
Nano-SIMNano-SIM + Nano-SIM |
|
|
|
| Build |
Glass front (Gorilla Glass 3), plastic back, plastic frame |
|
|
|
Display |
| Type |
Super AMOLED |
|
|
|
| Size |
6.4 inches, 100.5 cm2 (~84.9% screen-to-body ratio) |
|
|
|
| Resolution |
1080 x 2340 pixels, 19.5:9 ratio (~403 ppi density) |
|
|
|
| Protection |
Corning Gorilla Glass 3 |
|
|
|
Platform |
| OS |
Android 9.0 (Pie), upgradable to Android 11, One UI 3.0 |
|
|
|
| Chipset |
Exynos 9610 (10 nm) |
|
|
|
| CPU |
Octa-core (4x2.3 GHz Cortex-A73 & 4x1.7 GHz Cortex-A53) |
|
|
|
| GPU |
Mali-G72 MP3 |
|
|
|
Memory |
| Card Slot |
microSDXC (dedicated slot) |
|
|
|
| Internal |
64GB 4GB RAM, 64GB 6GB RAM, 128GB 4GB RAM, 128GB 6GB RAM |
|
|
|
|
UFS 2.1 |
|
|
|
Sound |
| Loudspeaker |
Yes |
|
|
|
| 3.5mm Jack |
Yes |
|
|
|
Comms |
| WLAN |
Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct |
|
|
|
| Bluetooth |
5.0, A2DP, LE |
|
|
|
| NFC |
Yes (market dependent) |
|
|
|
| Radio |
FM radio |
|
|
|
| USB |
USB Type-C 2.0, OTG |
|
|
|
| Positioning |
GPS, GLONASS, GALILEO, BDS |
|
|
|
Features |
| Sensors |
Fingerprint (under display, optical), accelerometer, gyro, proximity, compass |
|
|
|
|
ANT+
Bixby natural language commands and dictation |
|
|
|
Battery |
| Type |
Li-Po 4000 mAh, non-removable |
|
|
|
| Charging |
15W wired |
|
|
|
Misc |
| Colors |
Black, White, Blue, Coral |
|
|
|
| SAR EU |
0.27 W/kg (head) 1.39 W/kg (body) |
|
|
|
| Models |
SM-A505F, SM-A505FN, SM-A505GN, SM-A505G, SM-A505FM, SM-A505YN, SM-A505W, SM-A505X, SM-A505U, SM-A505GT, SM-A505U1, SM-A505G, SM-A505N, SM-S506DL |
|
|
|
| SAR |
1.31 W/kg (head) 0.58 W/kg (body) |
|
|
|
| Price |
About 270 EUR |
|
|
|
Main Camera |
| Features |
LED flash, panorama, HDR |
|
|
|
| Video |
1080p@30fps |
|
|
|
| Triple |
25 MP, f/1.7, 26mm (wide), PDAF
8 MP, f/2.2, 13mm (ultrawide), 1/4.0", 1.12µm
5 MP, f/2.2, (depth) |
|
|
|
Selfie camera |
| Single |
25 MP, f/2.0, 25mm (wide), 1/2.8", 0.9µm |
|
|
|
| Features |
HDR |
|
|
|
| Video |
1080p@30fps |
|
|
|
Tests |
| Performance |
AnTuTu: 144574 (v7)
GeekBench: 5396 (v4.4)
GFXBench: 8fps (ES 3.1 onscreen) |
|
|
|
| Display |
551 nits max brightness (measured) |
|
|
|
| Camera |
Photo / Video |
|
|
|
| Loudspeaker |
Voice 68dB / Noise 71dB / Ring 82dB |
|
|
|
| Battery (old) |
Endurance rating 98h |
|
|
|
| Audio quality |
Noise -93.4dB / Crosstalk -92.3dB |
|
|
|
